Valtek type injection rail automotive valve coil Φ 9.3 × 25mm DC12V 48W 1Ω 2Ω 5Ω 6Ω
The NJT209 coils are designed thermoplastic composite material or flame retardant temperature resistant resin.
The NJT209 coil system includes a wide range of electrical coils suitable for cartridge valves for LPG LNG and CNG system.
Tomasetto multi point pressure reducer automotive valve coil NJT204 suitable for automotive valve system.
Φ 9.3 × 25mm DC12V 48W ,Other special voltage and power could be customized
It can be supplied with different power consumptions according to specific requirements.
Specifications:
1. Model number:NJT209
2. Normal voltage:12VDC
3. Normal power: 17W 18W 48W (other voltage and power can be customized)
4. Color : Red , ( can be customized )
5. Inner Hole : Φ 9.3 × 25mm
6. Protect class : IP66
7. Insulation class : H
8. Connection Type : 16 × 0.8mm
9. Used to VALTEK series injection rail
10. Heavy duty long service life
Drawings:
Competitive Advantage:
High temperature resistant, excellent moistureproof property,widely used in car dual-fuel LPG/CNG modified
system, pressure reducer,motorcycle device etc.
Coil other parameter:
| Insulation temperature class | A | E | B | F | H |
| Maximum allowable temperature/degree | 105 | 120 | 130 | 155 | 180 |
| Permissible temperature rise(K) | 60 | 75 | 80 | 105 | 125 |
| Performance reference temperature/degree | 80 | 95 | 100 | 120 | 145 |
| Thermal margin | 5 | 5 | 10 | 10 | 15 |
| Maximum ambient temperature/degree | 40 | 40 | 40 | 40 | 40 |
